Description:

Honda V-twin engines offer high horsepower, great adaptability, quiet operation, and excellent fuel efficiency. Not to mention a 3-year warranty.

Specifications:

• Model: GX690
• Type: Air-cooled 4-stroke OHV (Overhead Valve)
• Bore x Stroke: 78 x 72 mm
• Displacement: 688 cc
• Net Power Output: 22.1 HP (16.5 kW) @ 3,600 RPM
• Net Torque: 35.6 lb-ft (48.3 Nm) @ 2,500 RPM
• PTO Shaft Rotation: Counterclockwise (from PTO side)

Key Features

• Compression Ratio: 9.3:1
• Carburetor: Horizontal type, two-barrel butterfly valve (internal vent)
• Ignition System: Digital CDI with variable timing (smooth starts, better efficiency)
• Starting System: Electric (reliable, no pull cord)
• Lubrication: Forced lubrication (better cooling & durability under heavy load)
• Governor: Mechanical (consistent RPM under varying loads)
• Air Cleaner: Dual-element (heavy-duty dust protection)

Fuel & Oil

• Fuel Type: Unleaded (86 octane or higher)
• Oil Capacity: 2.1 US qt (2.0L)
• Recommended Oil: SAE 10W-30 (check manual for extreme climates)

Dimensions & Weight

• Length: 15.9" (405 mm)
• Width: 16.1" (410 mm)
• Height: 17.2" (438 mm)
• Dry Weight: 96.8 lb (44 kg)

Electrical Options

• Lamp/Charge Coil Options: 2.7A, 17A, 26A (supports accessories like lights & alternators)

Durability & Compliance

• Warranty: Typically 3 years (consumer use) / 1 year (commercial)
• California Prop 65 Warning: Yes (contains chemicals known to cause cancer/reproductive harm)
